METAL CASE INDUSTRIAL GLASS THERMOMETERS
RG series
*APPLICATIONS
Metal case design protects effectively the thermometer from greasy and steam environment. Particularly used in vessel and environment with heat.
*SPECIFICATIONS
Type：
RGS － rigid straight stem；
RGL － rigid 90° angle stem
Case：
Material－Cylinder-shaped steel, chrome anodized
Size－120mmL x 19mmΦ；140mmL x 19mmΦ；150mmL x 19mmΦ；250mmL x 24mmΦ
Lens：Clear glass
Scale Plate：Aluminum, black markings on white background (single scale °C or °F)
Measuring Principle：Red or blue organic liquid (Non-toxic and environmentally safe)
Wetted Parts Material：
Brass；Chrome anodized
Stainless steel available made-to-order
Connection：1/2" PF (BSP) / PT / NPT standard (Other sizes are available upon request)
Stem Length (including length of thread)：50；60；95；110；125 mm
(Other lengths are available upon request)
Accuracy：±0.5/1/2/5/6°C
Range：-10~100；0~100；0~200；0~300；0~500；0~600°C
(Other ranges are available upon request)
