Digital LCD Display Bimetal Thermometer
D series
*APPLICATIONS
Used for all types of industrial applications, particularly for installation in tanks and pipelines. Combination with or without thermowell offers many possibilities for temperature measurement in liquid and gases media.
*SPECIFICATIONS
Dial Diameter：Φ3"；Φ4"
LCD Display：3 digits LCD display；Size：36 x 16mm
Case：Stainless steel 304
Connection：
Material－Stainless steel 304
1/4"；1/2" PT/NPT (others upon request)
Stem：
Material－Stainless steel 304
Length－6" (Include the length of thread) max.12"
Diameter－Φ7.6mm
Power Supply：1.5V x 2
Accuracy：±0.5% F.S.(liner deviation：±1.0% F.S.)
Temperature Range：From -50 to +150°C
(Ambient temperature：60°C)
