Digital LCD Display Bimetal Themometer
T series
*APPLICATIONS
Used for all types of industrial applications, particularly for installation in tanks and pipelines. Combination with or without thermowell offers many possibilities for temperature measurement in liquid and gases media.
*SPECIFICATIONS
Dial Diameter：Φ4" (105mm)
LCD Display：
4 digits LCD display；Size：58 x 23mm
Celsius & Fahrenheit value switchable
Case：
TR type in SUS304 or SUS316
All other types in black plated steel or SUS304 or SUS316
Connection：
Material－SUS201；SUS304；SUS316 (follow the material of stem)
M27x2；1/2" PT/NPT (others upon request)
Stem：
Material－SUS201；SUS304；SUS316
Length－min. 20mm, max. 3m (excluding thread)
Diameter－Φ6.0mm / 8.0mm / 10.0mm
Power Supply：1.5V x 1
Accuracy：±0.5°C (liner deviation：±1°C F.S.)
Temp. Range From -50 to +200 °C (-58 ~ 392°F)
