BIMETAL THERMOMETERS
Adjustable Angle Type
(adjustable angle range 90°)
BTA series
*APPLICATIONS
Used for all types of industrial applications, particularly for installation in tanks and pipelines. Combination with or without thermowell offers many possibilities for temperature measurement in liquid and gases media.
*SPECIFICATIONS
Dial diameter：Φ2.5"；3"；4"；5"；6"
Case：Stainless steel 304 case, IP65
Lens：Glass lens
Dial：Aluminum, black and red markings on white background
Pointer：Aluminum, black
Measuring principle：Coiled bimetal
Connection：
stainless steel 304 standard, stainless steel 316 available
Standard－
Fixed male thread 1/4" PT(BSPT) / NPT for dial Φ2.5"；3"
Fixed male thread 1/2" PT(BSPT) / NPT for dial Φ4"；5"；6"
< Other sizes or connection with male nut, union nut, compression fitting (sliding on stem) or plain stem (w/o fitting) are available upon request >
Stem：
Material－Standard Stainless steel 304 (Option：stainless steel 316)
Length－2" ~ 50" by order (minimum immersed length should be 2")
Diameter：Φ6.35mm (1/4") standard；Φ4mm, 6mm, 8mm, 9.5mm, 12mm available
Accuracy：±1% F.S.
Range：From -50 / +50 ℃ to 0 / +600℃ available (single scale ℃ or dual scale ℃ & ℉)
Optional extras：
1. Thermowell
2. Electrical contacts
